Features
POWERFULLY QUIET® OPERATION
Steam, smoke and odors are no problem for Thermador ducted ventilation systems.
BAFFLE FILTERS
Stainless steel commercial-style baffle filters maximize grease capture and they're dishwasher safe for easy clean-up.(VCIN and VCIB Series)
LED LIGHTING
Shed light on more of your exceptional moments. Thermador downdrafts feature multi-level, vivid LED lighting for everything, from setting the perfect dinner party mood to grabbing a quick midnight snack.
Specifications
General
Series Name
Professional® Series
Blower Included
No
Style
Chimney
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Wall Mount
Features
Wi-Fi
No
Dishwasher-Proof Filters
Yes
Technologies
Powerfully Quiet® system
Ducting Information
Diameter of air duct: Top 10"
Speeds
4-Stage settings
Additional Information
• Multi-level LED lights with fading transitions
• Automatic mode
• Check filter reminder light
• Delay shut-off
• Number of lights: 4
• Stainless-steel commercial style baffle filter
• Automatic mode
• Check filter reminder light
• Delay shut-off
• Number of lights: 4
• Stainless-steel commercial style baffle filter
Electrical Information
Information
• Volts: 120 V
• Frequency: 60 HZ
• Plug type: 120V-3 Prong
• Frequency: 60 HZ
• Plug type: 120V-3 Prong
Accessories
Included
Damper
Optional
• Remote blowers: VTR630W (600 CFM), VTR1030W (1000 CFM), VTR1330W (1300 CFM)
• Inline blowers: VTI610W (600 CFM), VTI1010W (1000 CFM)
• Integrated blowers: VTN630W (600 CFM), VTN1090R (1000 CFM)
• 25 ft. Blower connector cable: EXTNCB25W
• Roofplates: RFPLT600P, RFPLT1000P
• 6" Tall duct cover, 48" wide: CHMHP486W
• 18"- 35" Tall duct cover, 48" wide: CHMHP48TW
• 42"- 59" Tall duct cover, 48" wide: CHMHP48XTW
• Built-in remote control panel: REMCPW
• Roof jack: RJ310
• 8" Wall cap: WC8
• 10" Wall cap: WC10
• Inline blowers: VTI610W (600 CFM), VTI1010W (1000 CFM)
• Integrated blowers: VTN630W (600 CFM), VTN1090R (1000 CFM)
• 25 ft. Blower connector cable: EXTNCB25W
• Roofplates: RFPLT600P, RFPLT1000P
• 6" Tall duct cover, 48" wide: CHMHP486W
• 18"- 35" Tall duct cover, 48" wide: CHMHP48TW
• 42"- 59" Tall duct cover, 48" wide: CHMHP48XTW
• Built-in remote control panel: REMCPW
• Roof jack: RJ310
• 8" Wall cap: WC8
• 10" Wall cap: WC10
Dimensions
Class Width
36"
Width
47.94 inch(es) / 121.76 cm
Height
18 inch(es) / 45.72 cm
Depth
24 inch(es) / 60.96 cm
Weight
88.01 lb(s) / 39.92 kg
Additional Dimensions
Required distance above cooktop or range cooking surface: 30"
Warranty
Warranty
2-Year limited warranty on parts and labor
UPC
UPC#
825225931577
