Features
ACT™ CONTROL TECHNOLOGY
Airflow Control Technology (ACT) allows the installer to set the maximum fan CFM to align with local codes and regulations.
POWERWAVE™ 3-PHASE BLOWER TECHNOLOGY
Delivers best-in-class performance with unparalleled quiet operation. It provides more power while minimizing noise and improving efficiency.
CLEANAIR FUNCTION
CleanAir Function will turn the hood on once every four hours for 10 minutes to ensure the air is properly recirculated.
Specifications
General
Series Name
Pro Titan
Blower Included
Yes
Airflow
750 CFM
Style
Island
Color
Stainless Steel
Installation
Island
Features
Technologies
• Airflow Control Technology™ (ACT™)
• PowerWave™ Technology
• PowerWave™ Technology
Ducting Information
• Vertical Single Internal Blower: 8" Round
• Vertical Dual Internal Blower: 10" Round
• Vertical Dual Internal Blower: 10" Round
Speeds
• Speed Levels: 6**
• Single Blower: 200-750 CFM, 0.5-7 Sones
• ACT 590 CFM (Min. - Max.)*: 200-590 CFM
• ACT 390 CFM (Min. - Max.)*: 200-390 CFM
• ACT 290 CFM (Min. - Max.)*: 200-290 CFM
• Optional Dual Blower: 350-1,300 CFM, 1-8 Sones
• *ACT™ only available with single internal blower.
• **When ACT™ is enabled the number of fan speeds will be reduced to maximum 3 speeds.
• Single Blower: 200-750 CFM, 0.5-7 Sones
• ACT 590 CFM (Min. - Max.)*: 200-590 CFM
• ACT 390 CFM (Min. - Max.)*: 200-390 CFM
• ACT 290 CFM (Min. - Max.)*: 200-290 CFM
• Optional Dual Blower: 350-1,300 CFM, 1-8 Sones
• *ACT™ only available with single internal blower.
• **When ACT™ is enabled the number of fan speeds will be reduced to maximum 3 speeds.
Additional Information
• Electronic LCD
• Auto Delay-Off
• CleanAir Function
• Directional Lighting: LumiLight LED, 6W x2
• Dual-Level Lighting
• Filters: Pro Baffle x4
• Grease Collection Tray
• Duct Cover Extension Option
• Auto Delay-Off
• CleanAir Function
• Directional Lighting: LumiLight LED, 6W x2
• Dual-Level Lighting
• Filters: Pro Baffle x4
• Grease Collection Tray
• Duct Cover Extension Option
Electrical Information
Information
• AC POWER (Single Blower): 120V, 60Hz at Max. 5A
• AC POWER (Dual Blower): 120V, 60Hz at Max. 8A
• AC POWER (Dual Blower): 120V, 60Hz at Max. 8A
Certifications and Approvals
Information
ADA Compliant with remote accessory
Accessories
Optional
• Wireless Remote Control: 14000005
• Dual Internal Blower: PBD-1300B
• Duct Cover Extension: Z1C-0077
• Make-Up Air Kit (Single Blower): MUA008A
• Make-Up Air Kit (Dual Blower): MUA010A
• Dual Internal Blower: PBD-1300B
• Duct Cover Extension: Z1C-0077
• Make-Up Air Kit (Single Blower): MUA008A
• Make-Up Air Kit (Dual Blower): MUA010A
Dimensions
Class Width
36"
Width
36 inch(es) / 91.44 cm
Height
14.31 inch(es) / 36.35 cm
Depth
31.62 inch(es) / 80.32 cm
Additional Dimensions
Mounting Height Range: 24" - 36"
Warranty
Warranty
• 3 Years Limited on Parts
• 1 Year Limited Labor
• 1 Year Limited Labor
