Zephyr 34-inch Tornado I Series Built-in Hood Insert AK8134BS

ZephyrSKU: AK8134BS
The Tornado I provides muscle and flexibility in a small, barely-visible packaged beneath your custom hood enclosure. This 600-CFM insert... The Tornado I provides muscle and flexibility in a small, barely-visible packaged beneath your custom hood enclosure. This 600-CFM insert is upgraded with two hybrid baffle filters, dual-level LumiLight LED lighting, and an angled housing for a better fit within any custom hood. An optional adjustable-depth, stainless steel liner is available to protect your cabinetry and provide a more finished appearance. View more
Price:
$1,529.00
Specifications Documents
Specifications
General
Series Name
Tornado I
Blower Included
Yes
Airflow
600 CFM
Style
Custom Insert
Color
Stainless Steel
Installation
Built-In
Features
Ducting Information
• Vertical Internal Blower: 6" Round
• Horizontal Internal Blower: 6" Round
Speeds
3 Speeds
Additional Information
• Mechanical Slide Controls
• LumiLight LED, 6W x2
• Dual-Level Lighting
• Hybrid Baffle x2 Filters
• Recirculating Option
• Blower CFM (Min. - Max.): 200 - 600
• Sones (Min. - Max.): 1.4 - 6
Electrical Information
Information
120 V
Accessories
Optional
• 36" Liner (17-1/2" - 20-1/2" Depth): AK0836AS
• Recirculating Kit: ZRC-0080
• Make-Up Air Kit: MUA006A
Dimensions
Class Width
34"
Width
33.56 inch(es) / 85.24 cm
Height
12.37 inch(es) / 31.43 cm
Depth
11.19 inch(es) / 28.41 cm
Warranty
Warranty
10 years parts, 1 year labor
Documents
Installation Guide
Owners Manual
