Features
STAINLESS STEEL CONSTRUCTION
Crafted of heavy-duty stainless steel, it accommodates custom hood treatments, and is recommended for use with all Wolf cooking appliances.
RIGOROUSLY TESTED TO ENSURE DEPENDABILITY
Each and every Wolf appliance is rigorously stress-tested to perform for over twenty years of daily use and is backed by the strongest warranty in the industry.
WHISKS AWAY SMOKE AND ODORS
The Wolf Cooktop Downdraft rises 14 inches from the countertop to whisk away odors and smoke from the smallest saute pan to the largest stock pot.
DIRTY FILTER?
After approximately 30 hours of use, the filter clean indicator will illuminate, indicating that the filter needs to be cleaned.
Specifications
General
Blower Included
No
Style
Downdraft
Color
Stainless Steel
Installation
Countertop
Features
Dishwasher-Proof Filters
Yes
Additional Information
• Breathe cleaner air and enjoy less greasy residue in your kitchen
• Disappears when not in use for a sleek, minimal look and open-concept kitchens
• Lowers when not in use, and rises 14 inches to whisk away smoke and odors
• Matches the heavy-gauge stainless steel look of Sub-Zero, Wolf, and Cove
• Select from? internal, in-line, or remote blower options? (blower required)
• Automatically turns off the blower with a five-minute "delay-off" feature
• Minimizes the backward flow of cold air with backdraft transition
• Install a reversible motor box on either side of the downdraft for design flexibility
• Disappears when not in use for a sleek, minimal look and open-concept kitchens
• Lowers when not in use, and rises 14 inches to whisk away smoke and odors
• Matches the heavy-gauge stainless steel look of Sub-Zero, Wolf, and Cove
• Select from? internal, in-line, or remote blower options? (blower required)
• Automatically turns off the blower with a five-minute "delay-off" feature
• Minimizes the backward flow of cold air with backdraft transition
• Install a reversible motor box on either side of the downdraft for design flexibility
Electrical Information
Information
• 110/120 VAC, 60 Hz
• 15 A
• 15 A
Accessories
Optional
• 10" Round Inline Damper
• 8" Round Inline Damper
• Contemporary Cooktop/Downdraft Trim
• Make-Up Air Damper
• Recirculating Filter
• Recirculating Kit
• SRT Downdraft Trim
• 600 CFM Internal
• 600 CFM Inline
• 600 CFM Remote
• 1200 CFM Remote
• 8" Round Inline Damper
• Contemporary Cooktop/Downdraft Trim
• Make-Up Air Damper
• Recirculating Filter
• Recirculating Kit
• SRT Downdraft Trim
• 600 CFM Internal
• 600 CFM Inline
• 600 CFM Remote
• 1200 CFM Remote
Dimensions
Class Width
45"
Width
45 inch(es) / 114.3 cm
Height
14 inch(es) / 35.56 cm
Depth
2 inch(es) / 5.08 cm
Weight
85.01 lb(s) / 38.56 kg
Warranty
Warranty
2 Years Limited Warranty on Parts and Labor
