Specifications
General
Series Name
• Marine Collection
• MCR014
• 230V
• MCR014
• 230V
Capacity
11.99 lb(s) / 5.44 kg
Daily Ice Production
22.99 lb(s) / 10.43 kg
Color
White
Manufacturer Color
White
Cabinet Color
White
Hinge
Right
Features
Defrost
Manual
Ice Shape
Makes crescent-shaped cubes approx. 1/2" W x 3/4" H x 2 1/4" L
Reversible Door
Yes
Additional Information
• Model in White with flush to cabinet option
• Stainless steel handle (7/8" diameter)
• On / off switch
• White interior
• Field reversible door is shipped right-hand hinged
• Built-in or freestanding
• No drain required
• Refrigerant Type R600a
• Stainless steel handle (7/8" diameter)
• On / off switch
• White interior
• Field reversible door is shipped right-hand hinged
• Built-in or freestanding
• No drain required
• Refrigerant Type R600a
Electrical Information
Information
• Voltage/Hz: 230 / 50
• Amps: Running 1.2 amps
• Amps: Max Start Up 6 amps V
• Amps: Running 1.2 amps
• Amps: Max Start Up 6 amps V
Certifications and Approvals
Energy Star Certified
No
Accessories
Optional
• ULAWATERHOOKUP: Braided water supply line kit
• U-POWERCORD-2056: Power Cord 230 V Great Britain/Ireland
• U-POWERCORD-2256: Power Cord 230 V Australia/New Zealand
• U-POWERCORD-2667: Power Cord 230 V Continental Europe
• U-POWERCORD-3071: Power Cord 230 V China
• U-POWERCORD-3111: Power Cord 230 V India
• U-POWERCORD-2056: Power Cord 230 V Great Britain/Ireland
• U-POWERCORD-2256: Power Cord 230 V Australia/New Zealand
• U-POWERCORD-2667: Power Cord 230 V Continental Europe
• U-POWERCORD-3071: Power Cord 230 V China
• U-POWERCORD-3111: Power Cord 230 V India
Dimensions
Class Width
14"
Width
15.12 inch(es) / 38.4 cm
Height
25.12 inch(es) / 63.8 cm
Depth
17.01 inch(es) / 43.2 cm
Additional Dimensions
• Dimensions (FC): Product Depth 17" (432 mm)
• Dimensions (FC): Product Height 25 1/8" (638 mm)
• Dimensions (FC): Product Width 15 1/8" (384 mm)
• Dimensions (FC): Product Height 25 1/8" (638 mm)
• Dimensions (FC): Product Width 15 1/8" (384 mm)
Warranty
Warranty
• 1-Year (parts and labor)
• 5-Year sealed system (parts)
• 5-Year sealed system (parts)
