Features
DIGITAL TOUCH PAD CONTROL
Digital Touch Pad Control is conveniently located on upper face of unit.
CONVECTION COOLING SYSTEM
Convection cooling system rapidly and efficiently takes items to the set temperature
Specifications
General
Series Name
• HBV124
• 1 Class
• 1 Class
Type
Beverage Center
Installation
Built-In
Size
Compact
Color
Stainless Steel
Manufacturer Color
Stainless Frame
Cabinet Color
Black
Temperature Zones
1
Temperature Settings
34°F to 60°F
Hinge Side
Right
Capacity
Total Capacity
5.5 cu. ft.
Cans
105
Bottles
16
Wine Racks
2
Features
Digital Temperature Display
Yes
Glass Door
Yes
Interior Light
Yes
Reversible Door
Yes
Additional Information
• Stainless steel full-wrap door and handle (7/8" diameter)
• Stainless steel grille
• LowE coated, argon gas filled, dual thermopane glass door provides protection from harmful UV Light
• Volume of 5.5 cu ft holds up to 16 wine bottles (750 ml), and 85 bottles (12 oz) or 105 cans (12 oz)
• Convection cooling system provides a quick cool down and consistent temperature
• Extended lower interior maximizes storage options
• Black interior
• Two, three-quarter extension, black wine racks
• Two adjustable tempered glass shelves
• Digital touch pad control
• Bright white LED lighting
• Field reversible door is shipped right-hand hinged
• Built-in or freestanding (Freestanding kit required, sold separately)
• Four adjustable leveling legs
• Refrigerant type: R600a
• Stainless steel grille
• LowE coated, argon gas filled, dual thermopane glass door provides protection from harmful UV Light
• Volume of 5.5 cu ft holds up to 16 wine bottles (750 ml), and 85 bottles (12 oz) or 105 cans (12 oz)
• Convection cooling system provides a quick cool down and consistent temperature
• Extended lower interior maximizes storage options
• Black interior
• Two, three-quarter extension, black wine racks
• Two adjustable tempered glass shelves
• Digital touch pad control
• Bright white LED lighting
• Field reversible door is shipped right-hand hinged
• Built-in or freestanding (Freestanding kit required, sold separately)
• Four adjustable leveling legs
• Refrigerant type: R600a
Electrical Information
Information
• Voltage/Hz: 115 / 60
• Amps: Running (115 v): 1.2 A
• Amps: Running (115 v): 1.2 A
Certifications and Approvals
Sabbath
Yes
Accessories
Optional
ULAFREESTANDB: Freestanding Kit
Dimensions
Class Width
24"
Width
23.94 inch(es) / 60.8 cm
Height
34.13 inch(es) / 86.7 cm
Depth
22.52 inch(es) / 57.2 cm
Additional Dimensions
• Panel Height: 30 1/4" / 768 mm
• Panel Thickness: 3/4" / 20 mm
• Panel Type: 2 3/4" / 70 mm Frame or Solid Panel
• Panel Width: 23 3/4" / 603 mm
• Panel Thickness: 3/4" / 20 mm
• Panel Type: 2 3/4" / 70 mm Frame or Solid Panel
• Panel Width: 23 3/4" / 603 mm
Shipping Dimensions
Weight
120 lb(s) / 54.43 kg
Warranty
Warranty
• 1 Year for parts and labor
• 5 year limited on sealed system for parts only
• + Additional 1 Year (parts & labor) warranty at no cost with product registration
• 5 year limited on sealed system for parts only
• + Additional 1 Year (parts & labor) warranty at no cost with product registration
