Features
DIGITAL TOUCH PAD CONTROL
Digital Touch Pad Control is conveniently located on upper face of unit.
MECHANICAL COOLING SYSTEM (34°F - 45°F)
Mechanical cooling system offers a temperature range from 34°F - 45°F.
Additional Features
LED LIGHTING
The black interior is illuminated with LED lighting which automatically turns off when the door is closed.
Specifications
General
Type
Beverage Center
Installation
Built-In
Size
Compact
Color
Stainless Steel
Manufacturer Color
Stainless Frame
Temperature Zones
1
Temperature Settings
Temperature range: 34°F - 45°F
Hinge Side
Left
Capacity
Total Capacity
3.4 cu. ft.
Cans
87
Bottles
7
Wine Racks
2
Features
Technologies
• LowE coated, argon gas filled, triple thermopane glass door provides protection from harmful UV Light
• Convection cooling system rapidly and efficiently takes items to the set temperature
• Convection cooling system rapidly and efficiently takes items to the set temperature
Digital Temperature Display
Yes
Glass Door
Yes
Interior Light
Yes
Lock
Yes
Reversible Door
Yes
Additional Information
• Capacity: Bottle (12 oz): 51
• Capacity: Can (12 oz): 87
• Capacity: Wine Bottle (750 ml): 7
• Black interior is illuminated with LED lighting that automatically turns off when the door is closed, or can be set to stay on for 3 hours
• Full extension black coated wine racks allow for easy access
• Wine racks accommodate a variety of bottle shapes and sizes
• Three adjustable tempered glass shelves with 7 height positions
• Solid natural beech wood fronts on wine racks can easily be stained to match surrounding cabinetry
• Robust, concealed, and covered hinges with built-in door stop and closer
• Fixed grille can accept a 1/4" custom integrated toe-kick
• Four independently adjustable leveling legs provide a precise undercounter fit
• Capacity: Can (12 oz): 87
• Capacity: Wine Bottle (750 ml): 7
• Black interior is illuminated with LED lighting that automatically turns off when the door is closed, or can be set to stay on for 3 hours
• Full extension black coated wine racks allow for easy access
• Wine racks accommodate a variety of bottle shapes and sizes
• Three adjustable tempered glass shelves with 7 height positions
• Solid natural beech wood fronts on wine racks can easily be stained to match surrounding cabinetry
• Robust, concealed, and covered hinges with built-in door stop and closer
• Fixed grille can accept a 1/4" custom integrated toe-kick
• Four independently adjustable leveling legs provide a precise undercounter fit
Electrical Information
Information
• 115 Volts
• 60 Hertz
• 1.2 Amps
• 60 Hertz
• 1.2 Amps
Certifications and Approvals
Sabbath
Yes
Accessories
Optional
Integrated model requires 3/4" custom panel of your choice, or can accept U-Line Euro Style Handleless Stainless Panel Accessory (must be ordered separately)
Dimensions
Class Width
18"
Width
17.75 inch(es) / 45.09 cm
Height
33.69 inch(es) / 85.57 cm
Depth
23.44 inch(es) / 59.53 cm
Additional Dimensions
• Panel Height: 30" / 762 mm
• Panel Thickness: 3/4" / 20 mm
• Panel Type: 2 3/4" / 70 mm Frame Panel or Solid Panel (-60 suffix)
• Panel Width: 17 5/8" / 445 mm
• Panel Thickness: 3/4" / 20 mm
• Panel Type: 2 3/4" / 70 mm Frame Panel or Solid Panel (-60 suffix)
• Panel Width: 17 5/8" / 445 mm
Shipping Dimensions
Weight
127.01 lb(s) / 57.61 kg
Warranty
Warranty
Limited 1 year parts and labor
UPC
UPC#
833790040266
