Applicable Rebate
THERMADOR "ONE -TWO -FREE , YOUR GIFTS WITH PURCHASE"
Receive a FREE EMERALD DISHWASHER and choice of one (1) bonus gift with the purchase of complete qualifying kitchen suites. - Offer valid on purchases made between January 1, 2024 and June 30, 2024
See all qualifying products
Features
TRIPLE ELEMENT
Heat different sized cookware efficiently on the triple element.
Specifications
General
Series Name
Masterpiece®
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Fuel Type
Electric
Type
Built-In
Cooktop
Burners/Elements
5
Power Output
• Front Left Heating Element: 1,700 W
• Back Left Heating Element: 1,700 / 1,700 W
• Bridge Element: 4,000 W
• Back Right Heating Element: 1,200 W
• Center Heating Element: 3,080 / 2,200 / 1,050 W
• Front Right Heating Element: 2,200 / 1,000 W
• Back Left Heating Element: 1,700 / 1,700 W
• Bridge Element: 4,000 W
• Back Right Heating Element: 1,200 W
• Center Heating Element: 3,080 / 2,200 / 1,050 W
• Front Right Heating Element: 2,200 / 1,000 W
Burner/Element Size
• Front Left Heating Element: 7"
• Back Left Heating Element: 7"/ 5"
• Center Heating Element: 11"/ 8"/ 6"
• Back Right Heating Element: 6"
• Front Right Heating Element: 8", 6"
• Back Left Heating Element: 7"/ 5"
• Center Heating Element: 11"/ 8"/ 6"
• Back Right Heating Element: 6"
• Front Right Heating Element: 8", 6"
Elements
Smoothtop
Surface Features
• Heavy-duty stainless steel metal knobs provide precise control
• Full stainless steel frame surrounds the cooktop surface
• Full stainless steel frame surrounds the cooktop surface
Features
Wi-Fi
No
Downdraft Ventilation
No
Additional Information
• Dual zone bridge element accommodates oblong cookware and multiple diameter sizes
• Triple zone center element allows you to match element size to various sized cookware
• Variable 9-stage power setting offers a range of power from high heat to simmer
• Cooktop indicates when elements are still hot
• Triple zone center element allows you to match element size to various sized cookware
• Variable 9-stage power setting offers a range of power from high heat to simmer
• Cooktop indicates when elements are still hot
Electrical Information
Information
• 10,400 W
• 40 / 30 A
• 240 / 208 V
• 60 Hz
• 40 / 30 A
• 240 / 208 V
• 60 Hz
Accessories
Optional
CHEFSPAN08 - 10" Stainless Steel Pan
Dimensions
Class Width
36"
Width
37.01 inch(es) / 94.0 cm
Height
3.96 inch(es) / 10.05 cm
Depth
21.26 inch(es) / 54.0 cm
Weight
31 lb(s) / 14.06 kg
Additional Dimensions
• Required Cutout Size (HxWxD): 3 15/16" x 34 3/4" x 19 7/8"
• Minimum Distance From Counter Front: 2 1/4"
• Minimum Distance From Rear Wall: 2 3/4"
• Minimum Distance From Counter Front: 2 1/4"
• Minimum Distance From Rear Wall: 2 3/4"
Warranty
Warranty
Limited 2 years parts and labor
UPC
UPC#
825225924869
