Features
SOFTCLOSE® DOOR
SoftClose® feature prevents slamming and ensures ultra smooth closing of the Warming Drawer.
Specifications
General
Capacity
2.2 cu. ft.
Power
450 W
Color
Panel Ready
Manufacturer Color
Custom Panel Ready
Installation Type
Built-In
Features
Technologies
SoftClose® Hinges
Sabbath Mode
Yes
Indicator Light
Yes
Keep-Warm
Yes
Bread-Proofing
Yes
Additional Information
• Power Levels: Low, Med, High, Proof
• Temperature Settings: 100° – 190° F
• Timer: 5 min. – 5 hours
• Automatic Shut Off: After 1 hour
• Control Type: Illuminated Touch Control
• Drawer Installs Vertically Under Thermador Speed, Steam or Wall Oven
• Temperature Settings: 100° – 190° F
• Timer: 5 min. – 5 hours
• Automatic Shut Off: After 1 hour
• Control Type: Illuminated Touch Control
• Drawer Installs Vertically Under Thermador Speed, Steam or Wall Oven
Electrical Information
Information
• 120 V
• 60 Hz
• 15 A
• 60 Hz
• 15 A
Dimensions
Class Width
30"
Width
29.75 inch(es) / 75.57 cm
Height
9.44 inch(es) / 23.97 cm
Depth
24.5 inch(es) / 62.23 cm
Additional Dimensions
• Required Cutout Size (HxWxD) – Standard: 9 1/4" x 28 1/2" x 23 1/2"
• Required Cutout Size (HxWxD) – Flush*: 9 9/16" x 30" x 24 1/2"
• (*For WD30W, the installed dimensions may differ. This is based on 3/4" (19 mm) thick custom panel. Customer to provide custom panel and drawer handle)
• Required Cutout Size (HxWxD) – Flush*: 9 9/16" x 30" x 24 1/2"
• (*For WD30W, the installed dimensions may differ. This is based on 3/4" (19 mm) thick custom panel. Customer to provide custom panel and drawer handle)
Weight
55.01 lb(s) / 24.95 kg
Warranty
Warranty
Limited 2 Years Parts and Labor
UPC
UPC#
825225937210
