Specifications
General
Series Name
400 Series
Color
Black
Manufacturer Color
Black Glass
Fuel Type
Electric Induction
Type
Built-In
Cooktop
Burners/Elements
4
Power Output
• Element types (Front-L) - Power (Max/Booster) Inductor: 1400W / 1850W
• Element types (Front-R) - Power (Max/Booster) Inductor: 2300W / 3000W
• Element types (Rear-L) - Power (Max/Booster) Inductor: 2300W / 3000W
• Element types (Rear-R) - Power (Max/Booster) Inductor: 1400W / 1850W
• Element types (Front-R) - Power (Max/Booster) Inductor: 2300W / 3000W
• Element types (Rear-L) - Power (Max/Booster) Inductor: 2300W / 3000W
• Element types (Rear-R) - Power (Max/Booster) Inductor: 1400W / 1850W
Burner/Element Size
• Element types (Front-L) - Power (Max/Booster) Inductor: 5 - 3/4" 145 mm
• Element types (Front-R) - Power (Max/Booster) Inductor: 7 - 7/8" 200 mm
• Element types (Rear-L) - Power (Max/Booster) Inductor: 7 - 7/8" 200 mm
• Element types (Rear-R) - Power (Max/Booster) Inductor: 5 - 3/4" 145 mm
• Element types (Front-R) - Power (Max/Booster) Inductor: 7 - 7/8" 200 mm
• Element types (Rear-L) - Power (Max/Booster) Inductor: 7 - 7/8" 200 mm
• Element types (Rear-R) - Power (Max/Booster) Inductor: 5 - 3/4" 145 mm
Elements
Smoothtop
Features
Technologies
• Pot Detection System
• Induction Technology
• Induction Technology
Control Lock
Yes
Digital Display
Yes
Additional Information
• Cooling fan system
• Failure Codes indication
• Slide touch control for power setting
• Power levels: 1 to 9
• Digital display for power level indication
• Led bar for power level indication
• Melting Function 113°F / 45°C (inside the pot 108°F / 42°C)
• Booster/Fast boil function for each zone
• Heat up time automatic function for each zone
• Residual heat indication for each zone
• Minute minder functions for each zone + one general (Led Indicator): 1+4
• Key Lock (Led Indicator)
• Pause/recall (Led Indicator)
• General ON/OFF Key (Led Indicator)
• Dedicated ON/OFF Key for each zone
• Acoustic buzzer
• Failure Codes indication
• Slide touch control for power setting
• Power levels: 1 to 9
• Digital display for power level indication
• Led bar for power level indication
• Melting Function 113°F / 45°C (inside the pot 108°F / 42°C)
• Booster/Fast boil function for each zone
• Heat up time automatic function for each zone
• Residual heat indication for each zone
• Minute minder functions for each zone + one general (Led Indicator): 1+4
• Key Lock (Led Indicator)
• Pause/recall (Led Indicator)
• General ON/OFF Key (Led Indicator)
• Dedicated ON/OFF Key for each zone
• Acoustic buzzer
Electrical Information
Information
• kW / Amps rating at 240V, 60Hz: 7.20kW - 30A
• kW / Amps rating at 208V, 60Hz: 6.30kW - 30A
• kW / Amps rating at 208V, 60Hz: 6.30kW - 30A
Dimensions
Class Width
24"
Width
24.13 inch(es) / 61.3 cm
Height
2.87 inch(es) / 7.3 cm
Depth
20.98 inch(es) / 53.3 cm
Weight
33.07 lb(s) / 15 kg
Additional Dimensions
• Cut-out - Width: 22 - 5/8" 574 mm
• Cut-out - Height: 2 - 3/4" 68 mm
• Cut-out - Depth: 19 - 1/4" 490 mm
• Cut-out - Height: 2 - 3/4" 68 mm
• Cut-out - Depth: 19 - 1/4" 490 mm
