Specifications
General
Series Name
400 Series
Color
Black
Manufacturer Color
Black Glass
Fuel Type
Electric Induction
Type
Built-In
Cooktop
Burners/Elements
4
Power Output
• Right Front Element: Power L9 2300W, Booster 3000W
• Left Front Element: Power L9 1400W, Booster 1850W
• Left Rear Element: Power L9 2300W, Booster 3000W
• Right Rear Element: Power L9 1400W, Booster 1850W
• Left Front Element: Power L9 1400W, Booster 1850W
• Left Rear Element: Power L9 2300W, Booster 3000W
• Right Rear Element: Power L9 1400W, Booster 1850W
Burner/Element Size
• Right Front Element: 7 7/8"
• Left Front Element: 5 3/4"
• Left Rear Element: 7 7/8"
• Right Rear Element: 5 3/4"
• Left Front Element: 5 3/4"
• Left Rear Element: 7 7/8"
• Right Rear Element: 5 3/4"
Elements
Smoothtop
Surface Features
Elegant Ceramic glass surface
Features
Technologies
Induction Technology
Control Lock
Yes
Digital Display
Yes
Additional Information
• Slide touch control for power setting
• Melt Function
• Residual heat and Power on Indicators
• Digital Minute Minder
• Pot Detection System
• Independent timer for each zone
• Pause function
• Booster function for each cooking zone
• Failure Codes Indication
• Digital Display for Power Level
• Automatic Heat-up Time
• Melt Function
• Residual heat and Power on Indicators
• Digital Minute Minder
• Pot Detection System
• Independent timer for each zone
• Pause function
• Booster function for each cooking zone
• Failure Codes Indication
• Digital Display for Power Level
• Automatic Heat-up Time
Electrical Information
Information
• KW/Amps rating at 240V, 60Hz: 7.20kW - 30Amps
• KW/Amps rating at 208V, 60Hz: 6.30kW - 30Amps
• KW/Amps rating at 208V, 60Hz: 6.30kW - 30Amps
Certifications and Approvals
Information
UL
Dimensions
Class Width
24"
Width
24.12 inch(es) / 61.27 cm
Height
2.75 inch(es) / 6.99 cm
Depth
21 inch(es) / 53.34 cm
Shipping Dimensions
Weight
33 lb(s) / 14.97 kg
