Features
TRIPRO REFRIGERATION
Maximum freshness is guaranteed when each food product is preserved at the correct temperature and humidity levels. Such is the philosophy behind the TriPro Refrigeration system that ensures optimum preservation conditions thanks to the efficient separation of the Fridge, Fresco and Freezer compartments. Two cutting-edge compressors and three evaporators ensure continuous operation, maximum silence and energy savings.
PROVENT™ LATERAL AIRFLOW
Independent ventilation in each compartment and an even distribution of the cold airflow allow for uniform temperatures ensuring better preservation conditions. This unique air circulation reduces temperature fluctuations when the door is open.
TOTALNOFROST
Fhiaba's TotalNoFrost is a 100% automatic system that eliminates the need for Fridge, Fresco and Freezer defrosting.
TRIMODE™
Fridge, Fresco or Freezer: simply select the desired function through FhiabaAccess menu to modify the operating mode of the Bottom-Drawers.A versatile TriMode function allows for an extremely flexible management of the preservation environments, particularly when more units are installed.
FRESCO
A dedicated compartment with controlled temperature and humidity levels has been developed to guarantee an ideal preservation environment for fresh foods, delicacies and gourmet foods. Two spacious Fresco stainless steel drawers prevent the dispersion of cold air, the diffusion of odour and the cross-contamination between different compartments, allowing for high quality preservation of fresh produce, meats and fish.
ICEMAKER AND WATER FILTER
All models for food preservation are equipped with an automatic Ice Maker, connected directly to the water line. Ice cubes are always clear, odourless and tasteless thanks to the water filtering system installed in the fridge compartment.
The ice cube tray is positioned in a dedicated area of the bottom drawer, separated from all other preserved items. A sensor controls the level of ice cube in the dedicated tray, stopping and starting ice production according to the amount of ice cubes collected in the drawer.
EVENLIFT
Managing compartments organization and the functionalities of Fhiaba's preservation systems is extremely easy: its unrivalled flexibility has been developed to reach high levels of adaptability to modern life needs.
Thanks to EvenLift shelves, the interior set up of the Fridge compartment can be re-organized in a fast and simple manner, adapting to specific preservation needs.Bulky foods or containers easily and quickly find room in the compartment: the patented sliding shelves can be adjusted at any height without removing them, transforming the fridge interior in an organized and versatile space.
EQUILANCE™ HINGES
Patented hinge system with dual pivoting movement and self balancing roller will allow for as little as a 1/16” tolerance and can hold a total weight up to 220 lbs (100 kg).
OPTIVIEW
OptiView lighting system uses modern LED technology to ensure an optimal view of the interiors. Two LED arrays light the refrigerator compartment from above, while individual spot lights illuminatedirectly distinct areas of the fridge compartment, Fresco and TriMode drawers.
Additional Features
FHIABA ACCESS
Advanced electronic technology manages and monitors the entire refrigerator operations while the digital displays show the actual temperatures of the Fridge, Fresco and TriMode compartments as well as the date and time, thanks to the RealTime Clock system. Through the soft-touch control panel users can access the interactive menu to select the several available functions and customise the operation of the refrigerator according to personal needs. The user is alerted of any uncommon situation through text messages appearing on the display.
Specifications
General
Refrigerator Type
Bottom Freezer
Installation Type
Built-In
Door Hinge
Left
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Capacity
Total
18.3 cu. ft.
Refrigerator
13.5 cu. ft.
Freezer
4.8 cu. ft.
Refrigerator Features
Technologies
TriPro Refrigeration;
ProVent;
TotalNoFrost;
EvenLift;
OptiView.
Control Lock
No
Digital Display
Yes
Door Alarm
No
Frost Free
Yes
Interior Light
Yes
Wi-Fi
No
Crisper Drawers
Yes
Additional Information
EvenLift Shelves : 2;
Full-Width Door Racks : 3;
Anti-Bacterial Stainless Steel;
TriPro Refrigeration : 3 Settings; Fridge, Fresco, Freezer.
Ice and Water
Ice System
Interior
Water System
Interior
Filtration
Yes
Dispenser Features
IceMaker and Water Filter.
Dimensions
Class Width
35" to 37.9"
Class Height
70" and More
Width
35.37 inch(es) / 89.85 cm
Height (With Hinge)
84 inch(es) / 213.36 cm
Depth (Without Handles)
24 inch(es) / 60.96 cm
Weight
606.01 lb(s) / 274.88 kg
Additional Dimensions
Width : 29 1/2";
Depth : 24 3/4" without Handle;
Height : 84";
Niche Width : 30";
Depth with Door Open : 52";
Door Opening Angle : 105° Maximum;
Minimum Niche Height : 84".
Warranty
Warranty
• Full two year total product warranty
• Full five year sealed system - Product warranty - parts and labor
• Limited twelve year sealed system - Product warranty - parts only
• Full five year sealed system - Product warranty - parts and labor
• Limited twelve year sealed system - Product warranty - parts only
