Features
EVENLIFT
Managing compartments organization and the functionalities of Fhiaba's preservation systems is extremely easy: its unrivalled flexibility has been developed to reach high levels of adaptability to modern life needs.
Thanks to EvenLift shelves, the interior set up of the Fridge compartment can be re-organized in a fast and simple manner, adapting to specific preservation needs.Bulky foods or containers easily and quickly find room in the compartment: the patented sliding shelves can be adjusted at any height without removing them, transforming the fridge interior in an organized and versatile space.
EQUILANCE™ HINGES
Patented hinge system with dual pivoting movement and self balancing roller will allow for as little as a 1/16” tolerance and can hold a total weight up to 220 lbs (100 kg).
OPTIVIEW
OptiView lighting system uses modern LED technology to ensure an optimal view of the interiors. Two LED arrays light the refrigerator compartment from above, while individual spot lights illuminatedirectly distinct areas of the fridge compartment, Fresco and TriMode drawers.
TRIPRO REFRIGERATION
Maximum freshness is guaranteed when each food product is preserved at the correct temperature and humidity levels. Such is the philosophy behind the TriPro Refrigeration system that ensures optimum preservation conditions thanks to the efficient separation of the Fridge, Fresco and Freezer compartments. Two cutting-edge compressors and three evaporators ensure continuous operation, maximum silence and energy savings.
PROVENT™ LATERAL AIRFLOW
Independent ventilation in each compartment and an even distribution of the cold airflow allow for uniform temperatures ensuring better preservation conditions. This unique air circulation reduces temperature fluctuations when the door is open.
TOTALNOFROST
Fhiaba's TotalNoFrost is a 100% automatic system that eliminates the need for Fridge, Fresco and Freezer defrosting.
TRIMODE™
Fridge, Fresco or Freezer: simply select the desired function through FhiabaAccess menu to modify the operating mode of the Bottom-Drawers.A versatile TriMode function allows for an extremely flexible management of the preservation environments, particularly when more units are installed.
Additional Features
FHIABA ACCESS
Advanced electronic technology manages and monitors the entire refrigerator operations while the digital displays show the actual temperatures of the Fridge, Fresco and TriMode compartments as well as the date and time, thanks to the RealTime Clock system. Through the soft-touch control panel users can access the interactive menu to select the several available functions and customise the operation of the refrigerator according to personal needs. The user is alerted of any uncommon situation through text messages appearing on the display.
Specifications
General
Series Name
FK30
Refrigerator Type
Bottom Freezer
Installation Type
Built-In
Door Hinge
Right
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Capacity
Total
14.5 cu. ft.
Refrigerator
11.5 cu. ft.
Freezer
3.0 cu. ft.
Refrigerator Features
Technologies
• Super Cool
• OptiView™
• TriMode™
• EvenLift™
• EquiLance™
• OptiView™
• TriMode™
• EvenLift™
• EquiLance™
Digital Display
Yes
Frost Free
Yes
Interior Light
Yes
Crisper Drawers
Yes
Deli Drawer/Meat
Yes
Gallon Door
Yes
Additional Information
• Fully Integrated
• 2 Scrolling Glass Shelves
• 3 Adjustable Door Bins
• 2 Stainless Steel Drawers
• Refrigerator Compartment Temperature Range: From +36°F to +48°F.
• AISI 304 Stainless Steel Body
• AISI 304 Stainless Steel Interior and Panel Ready Exterior
• Optiview: Interior Contains 11 LED Light Spots
• Soft Closing Fridge Crisper Drawers
• Antibacterical Interiors
• Digital Temperature Display for Both Upper and Lower-Temperature Zone
• Acoustic and Visual Signals
• Front and Rear Adjustable Feet Up to 25mm in Height
• Low Vibration Dual Compressors
• TFT Full-Color Touch Screen Display
• 2 Scrolling Glass Shelves
• 3 Adjustable Door Bins
• 2 Stainless Steel Drawers
• Refrigerator Compartment Temperature Range: From +36°F to +48°F.
• AISI 304 Stainless Steel Body
• AISI 304 Stainless Steel Interior and Panel Ready Exterior
• Optiview: Interior Contains 11 LED Light Spots
• Soft Closing Fridge Crisper Drawers
• Antibacterical Interiors
• Digital Temperature Display for Both Upper and Lower-Temperature Zone
• Acoustic and Visual Signals
• Front and Rear Adjustable Feet Up to 25mm in Height
• Low Vibration Dual Compressors
• TFT Full-Color Touch Screen Display
Freezer Features
Additional Freezer Information
• TriMode™ Compartment Temperature Range: From +48°F to -8°F
• 1 Stainless Steel Drawer
• Soft Closing TriMode™ Drawer
• 1 Stainless Steel Drawer
• Soft Closing TriMode™ Drawer
Ice and Water
Ice System
Interior
Filtration
Yes
Electrical Information
Information
• 110 - 127 V
• 60 Hz
• 15 A
• 575 Kwh/year
• 60 Hz
• 15 A
• 575 Kwh/year
Certifications and Approvals
Sabbath Mode
Yes
Accessories
Optional
• Joining Kit - Central (Joining Brackets, Airflow Separation Included) KCCITU
• Extra Length Anti-tipping Kit B04000900
• Cleaning Kit Microfiber Cloth and 1 Magic Sponges RP00KP
• Extra Length Anti-tipping Kit B04000900
• Cleaning Kit Microfiber Cloth and 1 Magic Sponges RP00KP
Dimensions
Class Width
29" to 31.9"
Class Height
70" and More
Width
29.5 inch(es) / 74.93 cm
Height (With Hinge)
83.5 inch(es) / 212.09 cm
Depth (Without Handles)
25 inch(es) / 63.5 cm
Depth (With Handles)
27.25 inch(es) / 69.22 cm
Weight
437.99 lb(s) / 198.67 kg
Warranty
Warranty
2 Years Parts and Labor
