Specifications
General
Series Name
Plane NRS
Blower Included
Yes
Airflow
500 CFM
Style
Island
Color
Stainless Steel
Manufacturer Color
Scotch brite stainless steel (AISI 304)
Installation
Island
Features
Technologies
NRS technology for a quieter kitchen
Speeds
4
Additional Information
• Electronic control
• Lighting: LED 4 x 1,2 W - 3200 K
• Air Falmec filter for balanced suction
• Maximum capacity: 610 m³ /h, I.E.C. 61591
• Maximum noise level: 54,5 dB(A)re1pW, I.E.C.60704-2-13
• Maximum pressure: 582 Pa
• Lighting: LED 4 x 1,2 W - 3200 K
• Air Falmec filter for balanced suction
• Maximum capacity: 610 m³ /h, I.E.C. 61591
• Maximum noise level: 54,5 dB(A)re1pW, I.E.C.60704-2-13
• Maximum pressure: 582 Pa
Electrical Information
Information
• 120V, 60Hz
• Maximum consumption: 280 W
• Maximum consumption: 280 W
Accessories
Included
Standard with Nema 5-15P power cord
Optional
• KACL.572#I: Extension H1200 - Island
• KACL.815: Protective cleaning cloths for stainless steel (box 10 pcs)
• KACL.921: High Performance Filter
• KACL.815: Protective cleaning cloths for stainless steel (box 10 pcs)
• KACL.921: High Performance Filter
Dimensions
Class Width
36"
Width
36 inch(es) / 91.44 cm
Height
25.79 inch(es) / 65.5 cm
Depth
23.03 inch(es) / 58.5 cm
Weight
92.99 lb(s) / 42.18 kg
Additional Dimensions
• Max Height: 49"
• Minimum distance - Gas hob: 25"
• Minimum distance - Electric hob: 21"
• 3 x Metallic filter "Air Falmec" - Island 278 x 301 mm
• Minimum distance - Gas hob: 25"
• Minimum distance - Electric hob: 21"
• 3 x Metallic filter "Air Falmec" - Island 278 x 301 mm
Shipping Dimensions
Width
41 inch(es) / 104.14 cm
Height
27 inch(es) / 68.58 cm
Depth
30 inch(es) / 76.2 cm
Weight
109 lb(s) / 49.44 kg
Volume
19 cu. ft.
Warranty
Warranty
1-Year parts and labor
UPC
UPC#
8034122345895
