Features
PRO MOTOR
The motor in this hood is surrounded in metal with all metal impellers for top performance.
ADJUSTABLE MOUNTING HARDWARE
Wall brackets are adjustable once the hood is hung to ensure a perfect level installation.
BAFFLE GREASE FILTERS
Dishwasher safe SS metal filters capture grease and allow for easy clean up in the dishwasher.
Additional Features
DIRECT VENT
Top or direct rear venting (horizontal) to eliminate the need for extra ducting.
LED LIGHT
Energy efficient and cool to the touch LED lighting.
REMOTE CONTROL (OPTIONAL)
Control all features of the hood from the convenience of a wireless remote control. (sold separately)
VARIDUCT SYSTEM TOP AND REAR DIRECT VENTING
Easy kitchen integration with top and direct rear venting and recirculation options.
Specifications
General
Series Name
Nova Pro
Blower Included
Yes
Airflow
560 CFM
Style
Chimney
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Wall Mount
Features
Dishwasher-Proof Filters
Yes
Ducting Information
• Vari-Duct Top Or Direct Rear Venting
• 6" Round
• 6" Round
Speeds
4
Additional Information
• Pro Motor (Metal Impellers)
• Push Button Control With White LED
• Stainless Steel Baffle Grease Filter
• CFM: 150, 295, 395, 560 (Boost)
• Noise (Sones): 2.8, 4.3, 6.0, 7.5 (Boost)
• Power Watts: 250, 290, 350, 370 (Boost)
• 2x 5W LED Lighting
• Convertible to ductless
• Push Button Control With White LED
• Stainless Steel Baffle Grease Filter
• CFM: 150, 295, 395, 560 (Boost)
• Noise (Sones): 2.8, 4.3, 6.0, 7.5 (Boost)
• Power Watts: 250, 290, 350, 370 (Boost)
• 2x 5W LED Lighting
• Convertible to ductless
Accessories
Optional
• Wireless Remote Control: REMCTRL2
• High Ceiling Chimney Kit: HIGH3
• Ductless Conversion Kit: DUCT5
• Charcoal Filter Kit: FILTER1
• High Ceiling Chimney Kit: HIGH3
• Ductless Conversion Kit: DUCT5
• Charcoal Filter Kit: FILTER1
Dimensions
Class Width
36"
Width
35.37 inch(es) / 89.85 cm
Height
18.63 inch(es) / 47.31 cm
Depth
21.56 inch(es) / 54.77 cm
Warranty
Warranty
Limited 2 Years
UPC
UPC#
7612985608725
