Features
ELECTRONIC PUSH BUTTONS
Backlit electronic controls with a LED light to indicate the current speed. The indicator lights changes colors to indicate the speed / function.
LED LIGHTING
4 (W) LED energy efficient bulbs offer a warmer light for your cooking surface.
EASY SNAP MOUNTING CLIPS
Installation with easy with built-in adjustable clips that tighten onto the sides of the cabinet floor.
Specifications
General
Series Name
Inca Smart
Blower Included
Yes
Airflow
400 CFM
Style
Custom Insert
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Built-In
Features
Dishwasher-Proof Filters
Yes
Ducting Information
6" Round
Speeds
• 4 Speeds
• CFM: 150, 250, 350, 390
• CFM: 150, 250, 350, 390
Additional Information
• Electronic push with multi-colored LED controls
• Lighting: 2 X 4 (W) LED - 1 Level
• Dishwasher safe mesh grease filters
• Sound Levels: 3.0 - 6.0 Sones
• 10-Minute intensive speed
• Easy snap mounting lips
• Lighting: 2 X 4 (W) LED - 1 Level
• Dishwasher safe mesh grease filters
• Sound Levels: 3.0 - 6.0 Sones
• 10-Minute intensive speed
• Easy snap mounting lips
Accessories
Included
Power cord
Optional
• FILTER1 – Charcoal Filter Kit
• FILTER1LL – Long Lasting Charcoal Filter Kit
• WIREBOX – Fixed Wiring Box
• LINE30ST / LINE36ST – Stainless Steel Liner 30 and 36"
• FILTER1LL – Long Lasting Charcoal Filter Kit
• WIREBOX – Fixed Wiring Box
• LINE30ST / LINE36ST – Stainless Steel Liner 30 and 36"
Dimensions
Class Width
28"
Width
27.63 inch(es) / 70.17 cm
Height
12.75 inch(es) / 32.39 cm
Depth
11.25 inch(es) / 28.58 cm
Additional Dimensions
• Cut-out dimensions: 26-5/8" W x 10-1/4" D
• Mounting height from cooking surface: 24" - 30"
• Height inside cabinet: 12 3/4"
• Mounting height from cooking surface: 24" - 30"
• Height inside cabinet: 12 3/4"
Warranty
Warranty
Limited 2 Years
UPC
UPC#
7612985759311
