Features
LED PUSH BUTTONS
Updated Backlit electronic controls with a LED light to indicate the current speed.
PERIMETER ASPIRATION
Air is forced through narrow slots around the perimeter of the center panel greatly improving contaminant extraction.
PRO MOTOR
The motor in this hood is surrounded in metal with all metal impellers for top performance.
24 HOUR ANTI-POLLUTION MODE
This mode runs the hood for 10 minutes once an hour at a low CFM to refresh the air in your home.
Additional Features
DELAYED AUTO-OFF
Automatically turns the fan off after a set time (varies by the hood).
DIMMER LIGHT
A lower intensity light setting.
FILTER SATURATION ALARM
An indicator on the hood signals when to wash filters.
LED LIGHT
Energy efficient and cool to the touch LED lighting.
REMOTE CONTROL (OPTIONAL)
Control all features of the hood from the convenience of a wireless remote control. (sold separately)
INTENSIVE SPEED
Turns on at the highest speed for 10 minutes.
Specifications
General
Series Name
Cylindra Isola
Blower Included
Yes
Airflow
600 CFM
Style
Island
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Island
Features
Dishwasher-Proof Filters
Yes
Ducting Information
• 6" round
• Ducting top /direct rear
• Ducting top /direct rear
Speeds
• 4 Speeds (3 + BOOST)
• CFM: 150, 350, 450, 560
• Noise (Sones): 1.5, 2.5, 3.5, 6.5
• Power Watts: 115, 220, 270, 490
• CFM: 150, 350, 450, 560
• Noise (Sones): 1.5, 2.5, 3.5, 6.5
• Power Watts: 115, 220, 270, 490
Additional Information
• Pro Motor with metal impellers
• LED backlit electronic controls with a LED light indicator
• LED lighting two levels
• Dishwasher safe mesh grease filter
• Perimetric suction system / Silent kit
• 10-minute intensive speed
• 24-hour anti-pollution mode
• 30-minute auto shut off
• Grease filter wash indicator
• LED backlit electronic controls with a LED light indicator
• LED lighting two levels
• Dishwasher safe mesh grease filter
• Perimetric suction system / Silent kit
• 10-minute intensive speed
• 24-hour anti-pollution mode
• 30-minute auto shut off
• Grease filter wash indicator
Electrical Information
Information
AC Power: 490 watts / 4.1 amps
Accessories
Optional
• CFMRED – CFM Reducer Kit 300 CFM
• CFMRED2 - CFM Reducer Kit 400 CFM
• MUDAMPER6 / MUDAMPER8 – Universal Make-Up Air Damper
• FILTER2 – Charcoal Filter Kit
• REMCTRL2 – Remote Control
• Recirculating kit
• Glass kit
• CFMRED2 - CFM Reducer Kit 400 CFM
• MUDAMPER6 / MUDAMPER8 – Universal Make-Up Air Damper
• FILTER2 – Charcoal Filter Kit
• REMCTRL2 – Remote Control
• Recirculating kit
• Glass kit
Dimensions
Class Width
20" or Less
Width
14.56 inch(es) / 36.99 cm
Height
30.31 inch(es) / 76.99 cm
Depth
14.56 inch(es) / 36.99 cm
Additional Dimensions
Min. / max. ceiling height: 7' 6-5/16" - 8' 11-13/16"
Warranty
Warranty
Limited 2 Years
UPC
UPC#
7612985759304
