Specifications
General
Series Name
Dolomite
Type
Upright
Style
Built-In
Color
Panel Ready
Manufacturer Color
Panel Ready
Total Capacity
8.6 cu. ft.
Size Range
16 Cu.Ft. and Below
Reversible Door
Yes
Door Hinge
Right
Features
Additional Information
• Reversible Door: Field Reversible
• Interior Finish: White plastic liner
• Hinge Design: Articulating 90° opening flush hinge
• Refrigerant type: R600A
• Compressor: Donper
• Noise: Ultra Quiet 43 db(A)
• Lighting: LED 6500K 300 lumens, 100 lumen for Freezer
• Controls: Electronic Soft-Touch Digital Black Glass display
• Temperature range: +5°F (-15°C)to-11°F(-24°C)
• Shelving: 1 stationary + 3 Height adjustable cantilever Spill-Proof Glass shelves
• Drawers: 3 Large Freezer drawer (1 with interior divider and ice maker)
• Door Storage: 3 Height adjustable Bins
• Sabbath & Holiday Mode
• ECO Mode
• Soft close crisper & pantry drawers
• Ultra Quiet operation
• True Flush Install - 3D door adjustment
• Cool Day LED interior light side walls & ceiling
• Interior Finish: White plastic liner
• Hinge Design: Articulating 90° opening flush hinge
• Refrigerant type: R600A
• Compressor: Donper
• Noise: Ultra Quiet 43 db(A)
• Lighting: LED 6500K 300 lumens, 100 lumen for Freezer
• Controls: Electronic Soft-Touch Digital Black Glass display
• Temperature range: +5°F (-15°C)to-11°F(-24°C)
• Shelving: 1 stationary + 3 Height adjustable cantilever Spill-Proof Glass shelves
• Drawers: 3 Large Freezer drawer (1 with interior divider and ice maker)
• Door Storage: 3 Height adjustable Bins
• Sabbath & Holiday Mode
• ECO Mode
• Soft close crisper & pantry drawers
• Ultra Quiet operation
• True Flush Install - 3D door adjustment
• Cool Day LED interior light side walls & ceiling
Ice and Water
Ice and Water Dispenser
Interior Ice Maker
Additional Ice and Water Information
Interior Automatic Icemaker (3.9 lbs/day with basket capacity 5 lbs)
Electrical Information
Information
• Electric: 115V/60 Hz & 220-240 V/ 50-60Hz
• Plug Type: NEMA 5-15 P plug
• Power Cord Length: 7.5 feet
• Energy consumption: 452 kw/year V
• Plug Type: NEMA 5-15 P plug
• Power Cord Length: 7.5 feet
• Energy consumption: 452 kw/year V
Accessories
Optional
• 18" Stainless Steel Panel Kit: EPNKC18SS (³/4" deep)
• Pro Handle Stainless Steel Kit: EPHKCSS
• Tubular Handle Stainless Steel Kit: ETHKCSS
• Column Joining Kit: ECJKCXX
• Pro Handle Stainless Steel Kit: EPHKCSS
• Tubular Handle Stainless Steel Kit: ETHKCSS
• Column Joining Kit: ECJKCXX
Dimensions
Width
17.75 inch(es) / 45.09 cm
Height (With Hinge)
83.56 inch(es) / 212.25 cm
Depth (Without Handles)
23.31 inch(es) / 59.21 cm
Weight
209.99 lb(s) / 95.25 kg
Additional Dimensions
Cut Out Dimensions: 18 " W x 25" D x 84" H
Shipping Dimensions
Weight
231 lb(s) / 104.78 kg
Warranty
Warranty
Two (2) Years Parts & In-Home Labor. Earn an additional One (1) Year of Parts & In-Home Labor by registering on elica.com
