Features
BREATHE EASY WITH METAL GREASE FILTER
We know how much you love cooking, but dealing with the lingering grease and particles in the air? Not so much. That's why our ventilation system features a Metal Grease Filter. It's like a diligent little helper, quietly capturing grease and other solids from the air you breathe. And the best part? It's easy to clean - a quick wash by hand or a spin in the dishwasher, and it's ready to go again. So you can focus on cooking up a storm, while we take care of the air around you.
FILTERS THAT ARE DISHWASHER SAFE
Dishwasher safe mesh filters makes cleaning and maintenance easy.
Additional Features
TWO INCANDESCENT LIGHTS
Efficiently illuminate your cooktop to better see while cooking.
3 POWER LEVELS ALLOWS FOR GREATER CONTROL OF AIR CIRCULATION
Multiple power levels allow for customizing the amount of air circulation required for your cooking needs.
Specifications
General
Series Name
500 Series
Blower Included
Yes
Airflow
300 CFM
Style
Standard
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Wall Mount
Features
Dishwasher-Proof Filters
Yes
Ducting Information
• Diameter of air duct top: 7"
• Air duct back: 3 1/4" x 10" Rectangular
• Air duct back: 3 1/4" x 10" Rectangular
Speeds
3 Speeds
Additional Information
• Operating mode Convertible: ducted / recirculating
• Motor location Integrated motor: in hood body
• Number of lights: 2
• Bulb type: LED
• Light lumens: 250
• Light color: 3500 K
• Total power of the lamps: 3.2 W
• Damper included
• Grease filter material: Aluminum
• Grease filter type Multilayer: cassette
• Motor location Integrated motor: in hood body
• Number of lights: 2
• Bulb type: LED
• Light lumens: 250
• Light color: 3500 K
• Total power of the lamps: 3.2 W
• Damper included
• Grease filter material: Aluminum
• Grease filter type Multilayer: cassette
Electrical Information
Information
• 90 W
• 120 V
• 60 Hz
• 120 V
• 60 Hz
Accessories
Optional
Replacement charcoal filter HEZVEUD301
Dimensions
Class Width
30"
Width
30 inch(es) / 76.2 cm
Height
5 inch(es) / 12.7 cm
Depth
20 inch(es) / 50.8 cm
Weight
22.99 lb(s) / 10.43 kg
Additional Dimensions
Minimum distance above cooktop / range cooking surface: Min. 24" Electric / Min. 30" Gas
