Features
SUPER CLEANING SYSTEM
Rinse the dishes. Clean the interior, including the filter. Choose the best program. How many steps is that? One – and ASKO calls it the Super Cleaning System – or its best invention.
8 STEEL™ CONSTRUCTION
ASKO’s dishwashers are made of steel; no other dishwashers have so many details in steel instead of plastic. The container is held securely in the outer frame by four stainless bolts. This is a unique, durable solution that you will only find in an ASKO. No other material lasts as long as steel.
This is why we produce our dishwashers with eight of the most important components made of high-quality steel rather than plastic, such as: container, loading racks, spray pipe, spray arms, strainers, outer base, feet and heating element.
AQUA SAFE™
Do you hesitate to leave the dishwasher on while you are not at home? Aqua Safe™ system is an advanced safety system that ensures a leak-safe dishwasher day and night.
FLEXIRACKS™
ASKO Flexiracks™ from sturdy, nylon-coated steel and are easily adjustable in different heights depending on which type of load you have.
XXL DISHWASHER
ASKO's XXL dishwashers have a loading height of 22-3/4”. Combined with the smart four-level rack system the load is 40% more, with countless possibilities to make it all fit in.
SELF-CLEANING PROGRAM
ASKO’s dishwashers have a Self-cleaning program to ensure that all vital parts are thoroughly cleaned. Use a recommended cleaning agent and the program on a regular basis for the best result.
TIME PROGRAM
When you need clean plates in a hurry, just tell the machine how dirty the dishes are and how much time you have. The program then adjusts washing and rinsing to match your needs.
BRUSHLESS MOTOR
A brushless motor is not only quieter and more reliable. It also consumes less energy. You want your dishwasher to work forever. So do we.
SPEED MODE
When you need to get things cleaned in a hurry, the Speed mode is useful. It saves up to 50% of the normal time, by using more water and increased heating.
NIGHT MODE
Night mode reduces the noise by 2 dB thanks to lower pressure in the spray arm. Perfect at night or in a house with an open-plan living area.
RINCE & HOLD
The Rinse and hold program allows you to avoid dried leftovers while you wait for the dishwasher to get fully loaded. Saves time and energy over time.
AQUA LEVEL™ SENSOR
The Aqua Level™ Sensor ensures an optimized water level, even if a bowl turns over and is filled with water. It also keeps the machine from starting if the water is turned off.
AQUA DETECT™ SENSOR
The Aqua Detect™ Sensor monitors the inlet valve and the water level while the machine operates. For safety reasons, the drain pump’s capacity is five times the inlet valve’s.
POWER ZONE CUTLERY™
Power Zone Cutlery™ is a special nozzle spray zone for the cutlery basket that will make your cutlery dazzling clean. And, there is a similar nozzle for the knife basket.
KID SAFE™
To stop small fingers from starting the dishwasher the Kid Safe™ makes the control panel easy to lock. This also prevents altering any settings by mistake.
INSTANTLIFT™
ASKO's InstantLift™ height adjustment system allows for free-up between 40 and 58 mm in the upper basket. A simple and flexible way to make room for it all.
7 SPRAY™
ASKO’s spray system consists of up to 7 effective spray zones to ensure a totally clean load. In the lower rack, there are two power zones to take care of the dirtiest parts.
3-LEVEL BASKET
ASKO’s three-level rack system allows you to optimize the load. Remove, adjust, fold, and move the racks, tines, and cutlery basket to meet your every need.
TELESCOPIC RAILS
ASKO uses telescopic guide rails with ball bearings to make the racks glide smoothly and quietly. For easy loading and unloading, you can also take out the whole rack.
3-SPRAY ARMS
The 3 spray-arm technique reaches every corner and with up to 10 highly effective spray zones, no dirt can escape. Not even your lasagne baking dish.
CONDENSATION DRY
ASKO's system rapidly extracts condensation after the final wash so your dishes dry much faster.
TOUCHPROOF™
The ultra-thin, transparent TouchProof™ coating protects your dishwasher from stains and greases. Easy to clean and scratch resistant, it will keep your dishwasher looking brand new year after year.
16 PLACE SETTINGS
The world’s biggest load capacity. A flexible top cutlery tray with its own spray arm and space for sixteen sets of cutlery, small bowls, or other utensils that can be difficult to load. The width of the top cutlery tray has been optimized to make room for tall glasses in the upper basket and if more space is needed simply take the top cutlery tray out.
DOOR POP-OUT FUNCTION
When a program is completed, the Door Pop-Out function opens the dishwasher door automatically to remove the steam inside.
KNIFE HOLDERS
Knives are sensitive things, and so too are fingers. ASKO's knife holder is extra deep so that the blades remain steady throughout the wash cycle. There are knife holders on three levels: in the middle basket, in the upper basket, and in the top basket.
MULTI-POSITION GLASS RACK
The multi-position glass rack is a very practical rack that can be mounted in three different positions – all depending on your needs.
Specifications
General
Series Name
Logic
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Place Settings
16
Noise Level
48 dB(A)
Wash Cycles
Number of Cycles
7
Wash Cycles
• Rinse and hold program
• Intensive program
• Sanitize
• Standard
• Time program
• Self-cleaning
• Light wash
• Intensive program
• Sanitize
• Standard
• Time program
• Self-cleaning
• Light wash
Options
• Time set
• Heat Boost Mode
• Enable/disable automatic door opening
• Speed mode: the program time is shortened/more energy is used
• Night mode: lower noise level/the program time is extended
• Super Rinse™: 2 extra rinses
• Heat Boost Mode
• Enable/disable automatic door opening
• Speed mode: the program time is shortened/more energy is used
• Night mode: lower noise level/the program time is extended
• Super Rinse™: 2 extra rinses
Electrical Information
Information
• Estimated yearly energy consumption: 220 kWh
• Energy consumption - normal program: 1 kWh
• Power consumption in standby mode: 0.5 W
• Plug type: USA
• Connected load: 1300 W
• Voltage: 120 V
• Number of phases: 1
• Fuse: 15 A
• Frequency: 60 Hz
• Energy consumption - normal program: 1 kWh
• Power consumption in standby mode: 0.5 W
• Plug type: USA
• Connected load: 1300 W
• Voltage: 120 V
• Number of phases: 1
• Fuse: 15 A
• Frequency: 60 Hz
Features
Tub Material
Stainless Steel
Upper Basket Functions
• Small distance between the basket threads - makes loading easy and prevents small items to fall through
• Handle with plastic logotype
• Foldable wine shelves to the left
• Standard knife stand
• Fixed glass support
• Foldable wine shelves to the right
• Fixed pin rows
• Handle with plastic logotype
• Foldable wine shelves to the left
• Standard knife stand
• Fixed glass support
• Foldable wine shelves to the right
• Fixed pin rows
Lower Basket Functions
• Premium: Basket wiring in steel, fixed pin rows and removable cutlery basket
• Foldable/divisible rear pin row
• Cutlery basket
• Small distance between the basket threads - makes loading easy and prevents small items to fall through
• Handle with plastic logotype
• Foldable/divisible rear pin row
• Cutlery basket
• Small distance between the basket threads - makes loading easy and prevents small items to fall through
• Handle with plastic logotype
Technologies
• Kid Safe™: Lockable controls
• 8 Steel™
• Super Cleaning System™
• Cutlery Spray™
• InstantLift™ height adjustment system
• Aqua Level™ Sensor
• Aqua Detect™: Instant recognition of any leakage in the motor compartment
• Aqua Level™ Sensor: Ensures an optimized water level
• Anti Block™: Self-cleaning drain pump
Aqua Safe™:
• Sealing points outside the container
• Waterproof bottom plate
• Detection of water leakage on the bottom plate
• Stand-by water protection: Leakage detection when the machine is off
• Extra durable PEX inlet hose
• Maximum time for water intake
• Light and sound alarm
• 8 Steel™
• Super Cleaning System™
• Cutlery Spray™
• InstantLift™ height adjustment system
• Aqua Level™ Sensor
• Aqua Detect™: Instant recognition of any leakage in the motor compartment
• Aqua Level™ Sensor: Ensures an optimized water level
• Anti Block™: Self-cleaning drain pump
Aqua Safe™:
• Sealing points outside the container
• Waterproof bottom plate
• Detection of water leakage on the bottom plate
• Stand-by water protection: Leakage detection when the machine is off
• Extra durable PEX inlet hose
• Maximum time for water intake
• Light and sound alarm
Cutlery Tray
Yes
Control Lock
Yes
Additional Information
• Possible to delay up to 24 hours
• LCD display
• Remaining time indication
• Wash end indication: Displayed with sound and light
• Indication of low level of rinse-aid: Notification in display
• Max. temperature of inflow water: 140 °F
• Reference program: 1
• Duration of standard program: 125 min
• Estimated annual water consumption: 647.5 gal
• Water consumption: 3 gal
• Required inlet water pressure psi: 0,03-1
• Number of spray arms: 3 pcs
• Number of spray zones: 7
• Stainless steel spray arms
• Exterior handle: T-Bar
• Top tray: Easy height adjustment, handle, removable
• Upper rack type: Premium, fixed tines, and foldable wine shelves
• Installation: Multi-fit outlet hose, fixed high loop outlet hose, tip guard
• LCD display
• Remaining time indication
• Wash end indication: Displayed with sound and light
• Indication of low level of rinse-aid: Notification in display
• Max. temperature of inflow water: 140 °F
• Reference program: 1
• Duration of standard program: 125 min
• Estimated annual water consumption: 647.5 gal
• Water consumption: 3 gal
• Required inlet water pressure psi: 0,03-1
• Number of spray arms: 3 pcs
• Number of spray zones: 7
• Stainless steel spray arms
• Exterior handle: T-Bar
• Top tray: Easy height adjustment, handle, removable
• Upper rack type: Premium, fixed tines, and foldable wine shelves
• Installation: Multi-fit outlet hose, fixed high loop outlet hose, tip guard
Dimensions
Class Width
24"
Width
24.5 inch(es) / 62.23 cm
Height
34.69 inch(es) / 88.11 cm
Additional Dimensions
• Height setting: 1 "
• Depth: 24 15/16 "
• Maximum product height: 35 11/16 "
• Length of electrical cord: 71 7/16 "
• Depth with door open: 51 9/16 "
• Length inlet hose: 64 3/16 "
• Length outlet hose: 42 1/8 "
• Depth: 24 15/16 "
• Maximum product height: 35 11/16 "
• Length of electrical cord: 71 7/16 "
• Depth with door open: 51 9/16 "
• Length inlet hose: 64 3/16 "
• Length outlet hose: 42 1/8 "
Weight
158.71 lb(s) / 71.99 kg
Shipping Dimensions
Width
26.38 inch(es) / 67.01 cm
Height
39.75 inch(es) / 100.97 cm
Depth
29.5 inch(es) / 74.93 cm
Weight
178.6 lb(s) / 81.01 kg
